Source: Hobbymedia.it
- Similar wide dimensions (F103) to the KF-01: that was the motif of F1 machines of the 1990s.
- Uses strong FRP such as the main chassis plate. The racing design does not include unnecessary parts.
- External sections are anodized in black while pitching shock and side link are anodized in Kyosho’s signature red color.
- Suspension realizes stable performance through the front strut/center pivot and rear side link. Front/rear side springs provide reliable coil spring effect. Optional springs for Plazma Ra can be used.
- Features pitching shock with diaphragm and friction tube on roll damper (lazer etched with Kyosho logo).
Chassis Technical Data
|
| Length | 430mm |
| Width | 197mm |
| Ground Clearance | 5mm approx. |
| Wheelbase | 270mm |
| Tread (F/R) | 164mm / 166～172mm |
| Wheel（F/R） | Φ36mm x 30mm / Φ36mm x 45mm |
| Weight | 1,100g approx. |
| Motor | Brushless (sold separately) |
